Pulse voltage range

50~750V

50~750V

Pulse peak current

30A

50A

Output power max

10kW

1000W

Pulse frequency range

10000~80000kHz

10000~80000kHz

Pulse width range

0.5~95uS

0.5~95uS

Module synchronization

optical fiber

optical fiber

Waveform interface

optical fiber

optical fiber

Communication

BNC voltage/current

BNC voltage/current

Interface

RS485/TCP(Modbus)

                                              RS485/TCP(Modbus)

Application

Bias voltage synchronization, which can synchronize the production process with P3E and HiPIMS, and has three synchronization methods.

Bias voltage synchronization, which can synchronize the production process with P3E and HiPIMS, and has three synchronization methods.
